Sleek space-saving design
A perfect match for a small office desktop or department, a slimline profile ensures the DR-C225 II fits in the smallest space. With powerful CaptureOnTouch software and straightforward integration with cloud networks, it’s the ultimate space-saver.
A compact fit for tight spaces
Save even more space with this ultra-slim scanner. The innovative J-Path design ensures a small desktop footprint with ‘face up’ document scanning for easy use.
Ultra-slim, ultra-fast
Enjoy speedy duplex scanning of up to 50 ipm at 300 dpi and color speeds of up to 25 ppm. Ultrasonic Double Feed Detection also ensures reliable paper handling for fast scanning.
Outstanding operation
CaptureOnTouch software makes scanning simple. One-touch operation completes tricky tasks in seconds while Full Auto Mode intuitively selects the best settings.
Features
- Automatic document feeder
- CaptureOnTouch software
- Includes eCopy PDF Pro Office
- Double-sided scanning
- Wireless scanning of up to 25 ppm
- Windows and Mac compatible
- Cardiris
General product information
Type
Desktop Type Sheet Fed Scanner
Scanning sensor unit
CMOS CIS 1 Line Sensor
Optical resolution
600dpi
Light source
RGB LED
Scanning side
Simplex / Duplex / Folio / Skip Blank Page
Interface
High speed USB 2.0 (USB 3.0 compatible)
Dimensions (W x D x H)
Tray Closed : 300 (W) x 156 (D) x 220 (H)mm
Tray Opened: 300 (W) x 235 (D) x 339 (H)mm
Weight
Approx. 2.8kg
Power requirements
AC100 – 240V (50/60Hz)
Power Consumption
Scanning: 12.7W or less, Sleep mode: 1.8W or less, Power tuned off: 0.5W or less
Operating Environment
10 – 32.5 ?C (50 – 90.5 ?F), Humidity: 20 – 80% RH
Environmental compliance
RoHS and ENERGY STAR
Scanning specifications
Black and White
25ppm/50ipm
Colour
25ppm/50ipm
Output resolution
150dpi, 200dpi, 300dpi, 400dpi, 600dpi
Auto Resolution Setting
Colour Mode
Detect Automatically
Black and White
Error Diffusion
Advanced Text Enhancement I
Advanced Text Enhancement II (Windows only)
256-Level Grayscale
24-bit Colour
Daily duty cycle
Approx 1,500 scans/day
Document specifications
Width
J-Path : 50.8 – 216mm
Straight Through : 50.8 – 216mm
Length
J-Path : 70 – 356mm
Straight Through : 53.9 – 356mm
Thickness
J-Path : 52 – 128g/m? (0.06 – 0.15mm)
Straight Through : 40 – 209g/m? (0.05 – 0.25mm)
Long document mode
Straight Through : Up to 3000mm
Card scanning
Straight Through : 53.9 x 85.5 mm, Thickness less than 0.76 mm (Embossed Card is supported)
Paper separation
Retard Roller Method
Feeder capacity
45-sheets (A4, 80g/m?)
Special Features
Image Processing
Background Smoothing
Prevent Bleed Through/Remove Background
Erase Shadow
Colour Dropout (RGB)
Colour Enhancement (Red)
Moire Reduction
Double Feed Detection
Ultrasonic Sensor / By Length
Others
Automatic Page Size Detection
MultiStream
Prescan
Text orientation recognition
Deskew
Image Rotation
Job Setting
Bundled Software
Windows
ISIS /TWAIN Driver (Windows 2000/XP Pro/XP Home/Vista/7/8/10)
CaptureOnTouch
Nuance eCopy PDF Pro Office
CardIris
Plug-in: SharePoint, GoogleDocs, SugarSync, Dropbox, OneDrive
EMC Captiva Cloud Runtime controls
Mac
ISIS / TWAIN Driver
CaptureOnTouch
Plug-in: SharePoint, GoogleDocs, SugarSync, Dropbox, OneDrive
Consumables
Consumables
Exchange Roller Kit
