Gigabyte GeForce RTX 5060 Ti WindForce 8G Graphics Card (GV-N506TWF2-8GD)

Gigabyte GeForce RTXâ„¢ 5060 Ti WINDFORCE 8G, 2572 MHz, CUDA TBD, 28 Gbps, GDDR7, 128 bit, PCI-E 5.0, PSU 650W, DisplayPort 2.1b *3 HDMI 2.1b *1

The Gigabyte GeForce RTX 5060 Ti WINDFORCE 8G (GV‑N506TWF2‑8GD 1.0) is a dual‑fan NVIDIA GeForce RTX 5060 Ti‑based graphics card designed for mainstream gamers and creators. Built on NVIDIA’s next‑gen Blackwell architecture, it combines solid 1080p and capable 1440p gaming performance with modern features such as hardware ray tracing, DLSS 4, NVIDIA Reflex 2, AV1 encode/decode, and PCIe 5.0 compatibility — all in a compact, efficient dual‑slot package.

Key Features

NVIDIA Blackwell GPU & RTX 5060 Ti Performance

• Uses the NVIDIA GeForce RTX 5060 Ti GPU based on Blackwell 2.0, with 4608 CUDA cores, 36 4th‑gen RT cores for ray‑traced effects, and 144 5th‑gen Tensor cores for AI tasks like DLSS.Factory‑tuned boost clock ~2572 MHz improves responsiveness and frame rates vs. reference baseline.

Fast 8 GB GDDR7 Memory

• Equipped with 8 GB of GDDR7 VRAM on a 128‑bit bus running at 28 Gbps, delivering ~448 GB/s memory bandwidth — enough for most modern games at 1080p and some 1440p scenarios.

• While 8 GB is competitive for current titles, heavy future titles may demand more VRAM at ultra settings. Community commentary notes VRAM can limit performance as games evolve.

Efficient WINDFORCE Dual‑Fan Cooling

• WINDFORCE cooling system includes dual Hawk fans, server‑grade thermal gel, composite copper heat pipes, and copper baseplate for efficient thermal dissipation and quiet operation.

• Compact dual‑slot design (~208 × 120 × 40 mm) makes it suitable for smaller cases and builds.

• No RGB lighting (RGB‑free aesthetic) helps keep a clean look and reduced power draw.

Modern Connectivity & Features

• Interface: PCI Express 5.0 x8 for wide compatibility and future‑proofing.

• Display outputs include 3 × DisplayPort 2.1b and 1 × HDMI 2.1b, supporting up to 8K 7680 × 4320 resolution and multi‑display setups (up to 4 screens).

• Full support for DirectX 12 Ultimate, OpenGL 4.6, Vulkan, G‑SYNC, Resizable BAR, and NVIDIA ecosystem software (Broadcast, Studio, RTX Remix, etc.).

Balanced Power & System Requirements

• Typical power draw ~180 W, uses a single 8‑pin PCIe power connector, and recommends a 650 W PSU for stable system operation

• Smooth fit for mid‑tier desktops and small‑to‑mid‑tower builds without oversized cooling or PSU needs.

 Technical Specification
