TP-Link VIGI 4MP C240I(2.8mm) IR Dome Network Camera
$79.00 'inc. GST'
TP-Link VIGI 4MP C240I(2.8mm) IR Dome Network Camera, 4mm Lens, Smart Detection, 3YW
In stock
Vendor Code:
Description
VIGI 4MP IR Dome Network Camera
- 4MP Super-High Definition and IR Night Vision
- Human & Vehicle Classification
- Smart Detection
- Smart Video Enhancement Technology
- Built-In Microphone
- IP67 Waterproof and IK10 Vandal-Proof
- H.265+ Compression Technology
Specifications
CAMERA | |
| Image Sensor | 1/3” Progressive Scan CMOS |
| Shutter Speed | 1/3 to 1/10000 s |
| Slow Shutter | Yes |
| Minimum Illumination | Color: 0.01 Lux; 0 Lux with IR light |
| Day/Night Mechanism | IR Cut Filter |
| Day/Night Switch | Unified/ Scheduled/ Auto |
LENS | |
| Type | Fixed Focal Lens |
| Focal Length | 2.8 mm/4 mm |
| Aperture | • 2.8 mm: F2.2 |
| • 4 mm: F2.0 | |
| FOV | • 2.8 mm: |
| Horizontal FOV: 88.8°, Vertical FOV: 48.9°, Diagonal FOV: 106.5° | |
| • 4 mm: | |
| Horizontal FOV: 75.2°, Vertical FOV: 40.8°, Diagonal FOV: 88.3° | |
| Lens Mount | M12 |
| DORI Distance | • 2.8 mm: |
| Detect:60 m (197 ft) | |
| Observe: 25 m (82 ft) | |
| Recognize: 12 m (39 ft) | |
| Identify: 6 m (20 ft) | |
| • 4 mm: | |
| Detect: 80 m (262 ft) | |
| Observe:33 m (109 ft) | |
| Recognize: 16 m (52 ft) | |
| Identify: 8 m (26 ft) | |
Angle Adjustment (Manual) | |
| Range | • Pan: 0° to 355° |
| • Tilt: 0° to 75° | |
ILLUMINATOR | |
| IR LED | • Quantity: 2 |
| • Range: 30m | |
| • Wavelength: 850nm | |
| White LED | N/A |
| Illuminator On/Off Control | Auto/Scheduled/Always on/Always off |
Video | |
| Main Stream | • Frame Rate： |
| 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps | |
| 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps | |
| • Resolution: 2560×1440,2304×1296, 2048×1280, 1920×1080, 1280×720 | |
| Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. | |
| Sub-Stream | • Frame Rate： |
| 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps | |
| 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps | |
| • Resolution: 640×480,352×288, 320×240 | |
| Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. | |
| Bit Rate Control | CBR, VBR |
| Video Compression | • Main Stream: H.265+/H.265/H.264+/H.264 |
| • Sub-Stream: H.265/H.264 | |
| H.264 Type | High Profile |
| H.264+ | Main Stream Supported |
| H.265 Type | Main Profile |
| H.265+ | Main Stream Supported |
| Video Bit Rate | • Main Stream: 256 Kbps to 4 Mbps |
| • Sub-Stream: 64 Kbps to 512 Kbps | |
Image | |
| Image Settings | • Mirror |
| • Brightness | |
| • Contrast | |
| • Saturation | |
| • Sharpness | |
| • Exposure | |
| • WDR, | |
| • White Balance | |
| • Prevent Overexposure to Infrared Light | |
| • HLC Adjustable by Client Software | |
| • Rotation(90°/270°) | |
| Image Enhancement | BLC/3D DNR/HLC/SmartIR |
| Wide Dynamic Range | DWDR |
| SNR | ≥ 52 dB |
| Image Parameters Switch | Yes |
| Privacy Mask | Up to 4 Masks |
| ROI | 1 Region |
| OSD Setting | Yes |
AUDIO | |
| Audio Communication | N/A |
| Audio Input | Yes (Built-in Microphone) |
| Audio Output | N/A |
| Audio Compression | Yes |
| Audio Sampling Rate | 8KHz |
| Environment Noise Filtering | Yes |
| Audio Bit Rate | 64 Kbps(G.711 alaw) |
NETWORK | |
| Protocol | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP, RTMP |
| ONVIF | Yes |
| API | Open Network Video Interface (Profile S/T) |
| Simultaneous Live View | 3 Main Streams & 3 Sub-Streams |
| Client | VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS, VIGI Config Tool, VIGI PC Client |
| Web Browser | • Google Chrome® 57 and above |
| • Firefox® 52 and above | |
| • Safari® 11 and above | |
| • Microsoft® Edge 91 and above | |
| Cloud | Yes |
| Security | Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
ALARM AND EVENT MANAGEMENT | |
| Smart Event | • Intrusion Detection |
| • Line-Crossing Detection | |
| • Region Entering Detection | |
| • Region Exiting Detection | |
| • Object Abandoned/Removal Detection | |
| • Abnormal Sound Detection | |
| • People Detection | |
| • Vehicle Detection | |
| Basic Event | • Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts) |
| • Video Tampering Detection | |
| • Exception ( Illegal Login) | |
| Alarm Linkage | Message Push |
INTERFACES | |
| Network Interface | 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE |
| Alarm | N/A |
| Reset Button | N/A |
| Power | DC Power Port |
| On-board Storage | N/A |
| Built-in Microphone | Yes; Records Anything Going on within a 16.4-ft (5 m) Radius of the Camera |
| Built-in Speaker | N/A |
| Audio | N/A |
GENERAL | |
| Operating Temperature | -30 °C to 60 °C (-22 °F to 140 °F) |
| Storage Temperature | -40 °C to 60 °C (-40 °F to 140 °F) |
| Operating Humidity | 95% or Less (Non-Condensing) |
| Storage Humidity | 95% or Less (Non-Condensing) |
| Package Content | • VIGI Network Camera |
| • Quick Start Guide | |
| • Waterproof Cable Attachments | |
| • Mounting Accessories | |
| Material | Plastic |
| Net Weight | 0.27 Kg |
| Gross Weight | 0.45 Kg |
| Power Supply | • 12V DC ± 5%, Max. 5 W, 5.5mm Coaxial Power Plug |
| • PoE: 802.3af/at, class 0, Max. 5.5 W | |
| Protection | IP67 Waterproof, IK10 Vandal Proof |
| Product Dimensions (L x W x H) | 4.5 × 3.4 × 4.5 in (115 × 86 × 115 mm) |
| Certifications | CE, NTRA, VCCI, BSMI |
Additional information
| Weight | 0.46 kg |
|---|---|
| Dimensions | 19.3 × 15.3 × 12 cm |
| Brand | |
| Surveillance Cameras Type |
Dome Camera |
