CyberPower Smart App PR3000ERTXL2U Line-interactive UPS – 3 kVA/3 kW – 2U Rack/Tower – AVR – 3 Hour Recharge – 1.70 Minute Stand-by – 230 V AC Input – 220 V AC, 230 V AC, 240 V AC Output
CyberPower PR3000ERTXL2U with rackmount design guarantees power backup protection for home theatre systems, multimedia devices, IT equipment, computers, workstations, NAS/Storage devices, telecom devices, networking devices, and surveillance systems. The UPS adopts line-interactive topology with Automatic Voltage Regulation (AVR) function, and offers stabilized Pure Sine Wave output to ensure high power quality.
The UPS’s output power factor is 1, which means it is capable of connecting to more critical loads than conventional UPS. It also features Battery Management Technology to help batteries obtain optimal life span by balancing battery string voltage. Two-phase battery charging can charge the battery quickly and safely. The hot-swappable battery packs allow for easy maintenance without power interruption. Its multi-functional matrix LCD supports intuitive operation and quick configuration. The LCD panel is also rotatable to meet installation requirements.
Features
- Line-interactive UPS Topology
- Active PFC Compatible
- Toolless Battery Replacement
- High Output Power Factor
- Overload Protection
- Quick Charging Technology
- Extended Battery Module (EBM)
- EMI and RFI Filtration
- USB Connectivity Port
- Emergency Power Off (EPO) Port
Specifications
Controls/Indicators
| Status Indicators | LCD Information Display:
Operation Type Power Status Battery Status Load Status Fault & Warning Other Information Event & Log LED Indicators: Power On Line Mode Battery Mode UPS Fault Night Mode |
Interfaces/Ports
| Network (RJ-45) | Yes |
| Serial Port | Yes |
| EPO Port | Yes |
| USB (HID Compliant) Port | Yes |
Miscellaneous
| Package Contents | Smart App PR3000ERTXL2U 3000VA Rack/Tower UPS
Rackmount Rail Rackmount Ears Rail Kit Screw Kit Power Cord USB Cable Serial Cable EPO Cable User’s Manual |
| Environmentally Friendly | Yes |
| Environmental Certification | GreenPower UPS |
| RoHS | |
| Energy Star | Yes |
Environmental Conditions
| Thermal Dissipation | 432000 BTU/h |
| Maximum Operating Temperature | 40°C |
| Maximum Operating Elevation | 3 km |
| Maximum Storage Elevation | 15 km |
| Storage Relative Humidity | 0% – 95% |
| Sound Emission (A-Weighted) | 57.5 dB(A) |
Technical Information
| Application/Usage | Computer |
| Workstation | |
| Network Device | |
| Telecommunication | |
| Home Theatre | |
| Multimedia Device | |
| IT Equipment | |
| Surveillance System | |
| Overload Protection | Yes |
| Plug/Connector Type | IEC 60320 C20 |
| AU | |
| Phase | Single Phase |
| Receptacle Type | IEC 60320 C13 |
| IEC 60320 C19 | |
| EMI/RFI Noise Filter | Yes |
| AVR | Yes |
| Energy Saving | GreenPower UPS Bypass Technology |
| Number of Battery & Surge Outlets | 8 |
| Number of Critical Load Outlets | 4 |
| Transfer Time | 4 ms |
| Receptacle Detail | 2 x IEC 60320 C19 |
| 6 x IEC 60320 C13 |
Management
| Network Management | SNMP/HTTP Remote Monitoring |
| Alarm | Battery Mode |
| Overload | |
| Over-charge | |
| Low Battery | |
| Overheat |
Battery Information
| Battery Chemistry | Lead Acid |
| Hot Swappable | Yes |
| Backup/Run Time (Half Load) | 7.10 Minute |
| Backup/Run Time (Full Load) | 1.70 Minute |
| Battery Characteristics | Sealed |
| Replaceable Battery | Yes |
| Typical Battery Recharge Time | 3 Hour |
Physical Characteristics
| Weight (Approximate) | 32.79 kg |
| Form Factor | Rack/Tower |
| Rack Height | 2U |
| Height | 86.4 mm |
| Width | 434.3 mm |
| Depth | 500.4 mm |
| Product Color | Black |
General Information
| Product Type | Line-interactive UPS |
| Manufacturer Part Number | PR3000ERTXL2U |
| Manufacturer Website Address | http://www.cyberpower.com/au |
| Manufacturer | CyberPower Systems, Inc |
| Product Model | PR3000ERTXL2U |
| Product Name | Smart App PR3000ERTXL2U 3000VA Rack/Tower UPS |
| Product Line | Smart App |
| Brand Name | CyberPower |
Power Description
| Input Voltage | 230 V AC |
| Output Voltage | 220 V AC |
| 230 V AC | |
| 240 V AC | |
| Load Capacity | 3 kVA/3 kW |
| Surge Energy Rating | 2430 J |
| Waveform Type | Pure Sine Wave |
| Input Voltage Range | 159 V AC – 288 V AC |
| Output Frequency | 60 Hz |
| Input Frequency | 60 Hz |
