Gigabyte AORUS Gen5 14000 1TB PCIe5 NVMe2.0 M.2 SSD-SSD AG514K1TB M2 1TB 1.0

The Gigabyte AORUS Gen5 14000 SSD 1TB (SSD AG514K1TB) is an ultra-high-performance PCIe 5.0 x4 NVMe 2.0 M.2 SSD built for enthusiasts, gamers, and professional creators. Delivering incredible read speeds up to 13,600MB/s and write speeds up to 10,200MB/s, it dramatically reduces load times and accelerates demanding workloads. Featuring 3D TLC NAND, 2GB LPDDR4 DRAM cache, 700TBW endurance, and a 5-year warranty, the AORUS Gen5 14000 SSD offers next-generation speed, reliability, and efficiency for modern PC builds.

Specifications

• Interface PCI-Express 5.0×4, NVMe 2.0
• Form Factor M.2 2280
• Total Capacity 1000GB
• NAND 3D TLC NAND Flash
• External DDR Cache LPDDR4 2GB
• Sequential Read speed Up to 13,600 MB/s
• Sequential Write speed Up to 10,200MB/s
• Dimension 80 x 22 x 3.5 mm
• Mean time between failure (MTBF) 1.6 million hours
• Max. Operating Power Read : 11.5W; Write : 11.5W
• Power Consumption (Idle, PS3) < 144mW
• Power Consumption(PS4, L1.2) < 85mW
• Temperature (Operating) 0°C to 70°C
• Temperature (Storage) -40°C to 85°C

Warranty
1. Limited 5-years or 700TBW.
2. Limited warranty based on 5 years or 700TBW, whichever comes first. (*TBW is evaluated by JEDEC workload standard. )
*TBW (Terabyte Written): Terabytes Written is the total amount of data that can be written into a SSD before it is likely to fail.
3. When the usage of an NVME SSD as indicated by the ‘Percentage Used’ (SMART ID: 05) in SMART page of ‘GIGABYTE SSD toolbox’ reaches 100 means out of warranty. (A new unused product will show the number of 0)

Note
• Test system configuration: configuration may vary by models, we will choose the latest platform for verification.
• Performance may vary based on SSD’s firmware version and system hardware & configuration. Sequential performance measurements based on CrystalDiskMark and IOmeter 1.1.0.
• Speeds based on internal testing. Actual performance may vary.
• 1GB = 1 billion bytes. Actual useable capacity may vary.

* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
