StarTech 4 Port PCIe Gigabit NIC Network Adapter Card-ST1000SPEX43

StarTech 4 Port PCIe Gigabit NIC Network Adapter Card

Now you can add four separate Gigabit network ports to your client, server or workstation through just one PCI Express slot, to provide connectivity to multiple networks without draining your budget.

Reliable connectivity to multiple networks:

This 4-port network card delivers powerful connectivity for your business, corporate or government office environment, with support for high-performance, 4-channel networking and a maximum throughput of up to 1000Mbps in each direction (2000 Mbps total). The network adapter card features the Realtek RTL8111H chipset, which is designed to deliver the performance and enhanced capabilities you need for reliable network connections to your server or computer.

A versatile and cost-effective solution:

This versatile quad-port network card is ideal for many business applications requiring upgrades to servers or workstations, adding feature-rich Gigabit networking with four independent ports. Compatible with a broad range of operating systems, this cost-effective PCIe Gigabit NIC is suitable for many SMB and Enterprise applications such as virtualized environments that require multiple NICs (check your VM software for chipset compatibility).

Key Features:

• Add four independent Gigabit RJ45 ports to connect to multiple networks for high-bandwidth workstations and servers
• Realtek RTL8111H chipset for reliable performance
• Supports full-duplex flow control
• Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab networks
• Supports autonegotiation with next-page capacity
• Crossover detection and auto-correction (Auto-MDIX)
• Up to 9K jumbo frame support
• Support for IEEE 802.1Q VLAN tagging and IEEE 802.1P layer 2 priority encoding
• Microsoft NDIS5 checksum offload (IP, TCP, UDP) and large send offload support

Applications:

• Provides simultaneous access to multiple networks for desktop PC clients, servers, and workstations that have a limited number of PCI Express slots available
• Maximizes the number of RJ45 ports within a system or high-end workstations and servers
• Ideal for VM environments with multiple operating systems, requiring shared or dedicated NICs
• Provides redundant connectivity to ensure an uninterrupted network connection

 Specifications:
