TP-Link VIGI C340 (4mm Lens) 4MP Outdoor Full-Colour Bullet Network Camera

VIGI 4MP Outdoor Full-Colour Bullet Network Camera

• 4MP High Definition: The camera comes with 4MP–more than enough pixels to pick up some of the more discrete details.
• 24h Full-Colour: Obtain 24-hour colour details, even in pitch-black conditions, via a high-sensitivity sensor and included spotlight LEDs.
• Waterproof: Reliable IP66 for stable outdoor performance.
• Smart Detection (human detection, motion detection, area intrusion, line-crossing, video tampering): Receive notifications and check feeds when someone crosses a boundary, enter an area you’ve set, or obstructs the camera.
• H.265+: Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
• PoE/12V DC: Two power supply ways not only give you more convenience but also make your wiring remarkably easy.
• VIGI App: Manage your security from the palm of your hand with the VIGI app.

Specifications:

CAMERA

• Image Sensor :1/3″ Progressive Scan CMOS
• Lens :Fixed focal lens (2.8 mm / 4 mm / 6 mm)
• Aperture :2.8 mm: F1.6
  4 mm: F1.6
  6 mm: F1.6
• Lens Mount :M12
• Viewing Angle :(2.8mm) Horizontal FOV: 102°, Vertical FOV: 55°, Diagonal FOV: 122°
  (4mm) Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93°
  (6mm) Horizontal FOV: 50°, vertical FOV: 27°, Diagonal FOV: 59°
• Day/Night Mechanism :IR Cut Filter
• IR Working Distance :30m
• Illumination Distance :30 m
• Minimum Illumination :0 lux with IR/white Light
• Weatherproof Rating :IP66
• Digital Noise Reduction :3D DNR
• WDR :DWDR

NETWORK

• Security :Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
• Protocol :TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
• API :ONVIF
• Simultaneous Live View :3 Main Streams & 3 Sub-Streams

GENERAL

• Package Contents :VIGI Network Camera
  Quick Start Guide
  Waterproof Cable Attachments
  Mounting Accessories
• Operating Temperature :-30-60 °C
• Certifications :CE, RCM, BSMI, VCCI, RoHS, NTRA, KC
• Dimensions( H X W X D ) :78 x 70 x 174 mm
• Material :Plastic
• Weight :195g
• General Features :Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening
• Power Supply :12V DC ± 5%, 5.5mm Coaxial Power Plug
  PoE (802.3af/at, class 0)
• Power Consumption :12V DC: Max 7.5W
  PoE: Class 0

VIDEO/IMAGE

• Video Compression :Main stream: H.265+/H.265/H.264+//H.264
  Sub-Stream: H.265/H.264
• Frame Rate & Resolutions :Main Stream
  Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
  Resolution: 2560×1440, 2304×1296, 2048×1280, 1920x1080Sub-Stream
  Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
  Resolution: 640×480, 352×288, 320×240
• Video Streaming :Main Stream
  Sub-Stream
• Image Settings :Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software
• Image Enhancement :BLC/3D DNR/Prevent Overexposure to Infrared Light
• Video Bit Rate :Main Stream: 256 Kbps to 4 Mbps
  Sub-Stream: 64 Kbps to 512 Kbps

SMART FEATURE-SET

• Smart Event :Area Intrusion Detection, Line-Crossing Detection, Human Detection
• Basic Event :Motion Detection, Camera Tampering Detection, Exception ( illegal login)
• Linkage Method :Trigger Notification: ONVIF, HTTPS
• Region of Interest :1 Region

INTERFACES

• Network Interface :1 RJ45 10/100M Self-Adaptive Ethernet Port
• Audio Input :Built-in Microphone
• Audio Output :Built-in Speaker
• Button :Reset Button
• On-board Storage :Built-In Memory Card Slot, Support MicroSD Card, Up to 256 GB
• Built-in Microphone: Yes; Records Anything Going on within a 16.4-ft (5 m) Radius of the Camera
• Built-in Speaker: Yes
• Audio: N/A
