Dell Smart-UPS Standby UPS – 3 kVA/2.70 kW – 2U Rack-mountable – AVR – 3 Minute Stand-by – 230 V AC Input – 230 V AC Output – 8 x IEC 60320 C13, 1 x IEC 60320 C19
In addition to legendary reliability and manageability, Smart-UPS have extremely high efficiency at low, medium and high load levels making them ideal for today’s multi-core or virtualized servers that have varying load consumption.
Rack mounted Smart-UPS are ideal for powering Blade or density optimized servers in a distributed power protection environment as the primary or redundant protection. Smart-UPS models have long been considered the benchmark for all network and server UPS’s.
Smart-UPS feature a 16-segment LED display, extended range automatic voltage regulation (AVR), and pure sine wave output on battery.
- Boost and trim automatic voltage regulation (AVR)
- Intelligent battery management
- Power conditioning
- Temperature-compensated battery charging
- Automatic restart of loads after UPS shutdown
- Automatic self-test
- Cold-start capable
- Disconnected battery notification
Specifications
Controls/Indicators
| Status Indicators | LCD Display |
Management
| Alarm | Alarm |
Warranty
| Limited Warranty | 3 Year |
Battery Information
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 3 Minute |
Interfaces/Ports
| Serial Port | Yes |
| EPO Port | Yes |
| USB (HID Compliant) Port | Yes |
Miscellaneous
| Package Contents | Smart-UPS 3000VA Rack-mountable UPS
Rack Mounting Kit |
| Environmentally Friendly | Yes |
| Environmental Certification | REACH |
| RoHS |
Power Description
| Input Voltage | 230 V AC |
| Output Voltage | 230 V AC |
| Load Capacity | 3 kVA/2.70 kW |
| Surge Energy Rating | 459 J |
| Waveform Type | Sine Wave |
| Pure Sine Wave | |
| Input Voltage Range | 150 V AC – 300 V AC |
| Output Frequency | 60 Hz |
| Input Frequency | 60 Hz |
Technical Information
| Plug/Connector Type | IEC 60320 C20 |
| Receptacle Type | IEC 60320 C13 |
| IEC 60320 C19 | |
| AVR | Yes |
| Receptacle Detail | 1 x IEC 60320 C19 |
| 8 x IEC 60320 C13 |
General Information
| Product Type | Standby UPS |
| Manufacturer Part Number | AA869897 |
| Manufacturer Website Address | http://www.dell.com.au |
| Manufacturer | Dell Technologies |
| Product Name | Smart-UPS 3000VA Rack-mountable UPS |
| Product Line | Smart-UPS |
| Brand Name | Dell |
Physical Characteristics
| Weight (Approximate) | 44.28 kg |
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| Height | 86 mm |
| Width | 480 mm |
| Depth | 683 mm |
| Product Color | Black |
