CAMERA
|
| Image Sensor |
1/3.06” Progressive Scan CMOS |
| Shutter Speed |
1/3 to 1/10000 s |
| Slow Shutter |
Yes |
| Minimum Illumination |
0.005 Lux; 0 Lux with IR/White Light |
| Day/Night Mechanism |
IR Cut Filter |
| Day/Night Switch |
Unified/ Scheduled/ Auto |
LENS
|
| Type |
Fixed Focal Lens |
| Focal Length |
4 mm |
| Aperture |
F1.6 |
| FOV |
Horizontal FOV: 80°, Vertical FOV: 43°, Diagonal FOV: 94° |
| Lens Mount |
M12*0.5 |
| DORI Distance |
Detect: 80 m (262 ft)
Observe: 33 m (109 ft)
Recognize: 16 m (52 ft)
Identify: 8 m (26 ft) |
PTZ
|
| Pan/tilt Range |
Pan: 0° to 348°, Tilt: 0° to 120° |
| Pan/tilt Speed |
• Pan Speed:
Configurable from 8° to 44°/s; Preset Speed: 44°/s• Tilt Speed:
Configurable from 8° to 44°/s, Preset Speed 44°/s |
| Manual Control Speed |
Configurable from 8° to 35°/s |
| Presets |
300 |
| Patrol Scan |
8 patrols, up to 8 presets for each patrol |
| Power-off Memory |
Yes;
Auto restore to previous PT and lens status after power failure |
| Park Action |
Yes;
Preset; Patrol Scan |
| 3D Positioning |
Yes |
ANGLE ADJUSTMENT (MANUAL)
|
| Range |
• Pan: 0° to 348°
• Tilt: 0° to 120° |
| ILLUMINATOR |
|
| IR LED |
• Quantity: 2
• Range: 30m
• Wavelength: 850nm |
| White LED |
• Quantity: 2
• Range: 30m |
| Illuminator On/Off Control |
Auto/Scheduled/Always on/Always off |
VIDEO
|
| Max. Resolution |
2560 X 1440 |
| Main Stream |
• Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps• Resolution:
2560×1440, 2304×1296, 2048×1280, 1920×1080, 1280x720Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
| Sub-Stream |
• Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps• Resolution:
640×480, 352×288, 320x240Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
| Bit Rate Control |
CBR, VBR |
| Video Compression |
• Main Stream: H.265+/H.265/H.264+/H.264
• Sub-Stream: H.265/H.264 |
| H.264 Type |
Main Profile/High Profile |
| H.264+ |
Main Stream Supported |
| H.265 Type |
Main Profile |
| H.265+ |
Main Stream Supported |
| Video Bit Rate |
• Main Stream: 256 Kbps to 3 Mbps
• Sub-Stream: 64 Kbps to 512 Kbps |
|
| Image Settings |
• Mirror
• Brightness
• Contrast
• Saturation
• Sharpness
• Exposure, WDR,
• White Balance
• Prevent Overexposure to Infrared Light
• HLC Adjustable by Client Software
• Rotation (90°/270°) |
| Image Enhancement |
BLC/3D DNR/HLC/SmartIR |
| Wide Dynamic Range |
DWDR |
| SNR |
≥ 52 dB |
| Image Parameters Switch |
Yes |
| Privacy Mask |
Up to 4 Masks |
| ROI |
1 Region |
| OSD Setting |
Yes |
AUDIO
|
| Audio Communication |
Two-Way Audio |
| Audio Input |
Yes |
| Audio Output |
Yes |
| Audio Compression |
Yes |
| Audio Sampling Rate |
8KHz |
| Environment Noise Filtering |
Yes |
| Audio Bit Rate |
64 Kbps(G.711 alaw) |
NETWORK
|
| Protocol |
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| ONVIF |
Yes |
| API |
ONVIF |
| Simultaneous Live View |
2 Main Streams & 2 Sub-Streams |
| Client |
VIGI App, VIGI Security Manager, Web UI |
| Web Browser |
• Google Chrome® 57 and above
• Firefox® 52 and above
• Safari® 11 and above
• Microsoft® Edge 91 and above |
| Cloud |
Yes |
| Security |
Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
4G
|
| Standard |
LTE-TDD/LTE-FDD/WCDMA |
| SIM Type |
Nano SIM |
| Category |
4 |
| Frequency |
• LTE-FDD: B 1/3/5/7/8/20/28
• LTE-TDD: B 38/40/41
• WCDMA: B 1/5/8 |
ALARM AND EVENT MANAGEMENT
|
| Smart Event |
• Human & Vehicle Classification
• Intrusion Detection
• Line-Crossing Detection
• Region Entering Detection
• Region Exiting Detection
• Object Abandoned Detection
• Object Removal Detection
• People Detection
• Vehicle Detection |
| Basic Event |
• Motion Detection
• Video Tampering Detection
• Exception (Illegal Login) |
| Alarm Linkage |
• Memory Card Video Recording
• Message Push
• Audible Warning
• White Light Flashing |
| Linkage Method |
N/A |
| Output Notification |
Message Push |
INTERFACES
|
| Network Interface |
1 RJ45 10/100M Self-Adaptive Ethernet Port |
| Alarm |
N/A |
| Reset Button |
Yes |
| Power |
DC Power Port |
| On-board Storage |
Built-In Memory Card Slot, Support MicroSD Card, Up to 512 GB |
| Built-in Nano-SIM Card Slot |
Yes |
| Built-in Microphone |
Yes; Records Anything Going on within a 15-ft Radius of the Camera |
| Built-in Speaker |
Yes |
| Audio |
N/A |
GENERAL
|
|
| Operating Temperature |
-30–60 °C |
| Storage Temperature |
-40–60 °C |
| Operating Humidity |
95% or Less (Non-Condensing) |
| Storage Humidity |
95% or Less (Non-Condensing) |
| Package Contents |
• VIGI Network Camera
• Quick Start Guide
• Waterproof Cable Attachments
• Mounting Accessories
• Power Adapter |
| Material |
Plastic |
| Net Weight |
0.69 Kg |
| Gross Weight |
1.16 Kg |
| Power Supply |
12V DC/1A, 5.5mm Coaxial Power Plug |
| Antenna |
• Quantity: 2
• Type:
690~960&1710~2690MHz Dipole Omni-Directional Antenna
• Gain:
Ant1:0.84dBi@690~960MHz, 2.85dBi@1710~2690MHz
Ant2:0.74dBi@690~960MHz, 3.06dBi@1710~2690MHz |
| Protection |
IP66 |
| Product Dimensions (L x W x H) |
120 × 182 × 201 mm (excluding antennas) |
| Certifications |
CE, RCM, BSMI, RoHS, NCC |
