CyberPower Online S OLS6000ERT6UM Double Conversion Online UPS – 6 kVA/5.40 kW – 3U Rack/Tower – 7-Hour Recharge
CyberPower OLS6000ERT6UM is a high-performance UPS featuring online double-conversion topology, which provides seamless pure sine wave power for mission-critical devices such as NAS and servers, DVRs/surveillance systems, transportation and infrastructure, and emergency systems. It’s typically integrated in the back office, server room, and data center environment.
By manually setting the UPS to ECO Mode, the UPS automatically detects the input power quality and discerns whether it should operate in Line Mode or ECO Mode. Under poor power conditions, the UPS will run in Line Mode, which guarantees the highest level of protection and the best possible power quality. When the input power quality is acceptable, the UPS switches to ECO Mode, which increases the total output power efficiency by up to 96%.
The product is equipped with a Maintenance Bypass Switch. By flipping the switch, the power supply is safely transferred to utility. This allows service personnel to carry out fast on-site maintenance without having to shut down any connected equipment.
Features
- Online (Double Conversion) UPS Topology
- Energy Saving Technology
- UPS Parallel Expansion
- Generator Compatible
- Overload Protection
- Maintenance Bypass Switch
- Zero Transfer Time
- Smart Battery Management (SBM)
- Extended Battery Module (EBM)
- Surge and Spike Protection
- EMI and RFI Filtration
- LCD Status Display
- Emergency Power Off (EPO) Port
- PowerPanel® Management Software
- SNMP/HTTP Remote Management Capability (Optional)
- Rack/Tower Convertible Configurations
Application
- Data Closets
- NAS & Servers
- Home Theater Systems
- DVRs/Surveillance Systems
- POS Systems
- Transportation & Infrastructure
- Vehicle/Yacht
- Emergency Systems
- Electric Lighting
- Back Office
- Server Room
- Data Center
Feature Focus
Extended Runtime
Extended runtime is critical for most power demanding electronic devices. The installation of CyberPower’s external battery modules allows scalable system runtime, guaranteeing higher system availability that ensures clean, uninterrupted power to protected equipment even during a power outage.
Smart Battery Management
Batteries are normally consider as a consumable item that requires replacement on a regular basis. To further prolong battery life span, UPS adopted with Smart Battery Management technology uses a 3-cycle approach and temperature compensation method which efficiently reduces battery maintenance cost and achieves a lower total cost of ownership.
Specifications
Controls/Indicators
Status Indicators |
Line Mode
Battery Mode
Bypass Mode
UPS Fault |
Warranty
Interfaces/Ports
Serial Port |
Yes |
EPO Port |
Yes |
Miscellaneous
Environmentally Friendly |
Yes |
Environmental Certification |
RoHS |
Environmental Conditions
Thermal Dissipation |
1603 BTU/h |
Maximum Operating Elevation |
2 km |
Maximum Storage Elevation |
15 km |
Operating Humidity |
0% – 90% |
Storage Relative Humidity |
0% – 95% |
Storage Temperature |
-15°C – 45°C |
Physical Characteristics
Weight (Approximate) |
17.51 kg |
Form Factor |
Rack/Tower |
Rack Height |
3U |
Height |
130.5 mm |
Width |
438 mm |
Depth |
680 mm |
Technical Information
Application/Usage |
Office |
Transportation |
Server Room |
Surveillance System |
POS Terminal |
Emergency System |
DVR |
Server |
Home Theatre |
Data Center |
Overload Protection |
Yes |
Plug/Connector Type |
Terminal Block |
Phase |
Single Phase |
Receptacle Type |
Terminal Block |
EMI/RFI Noise Filter |
Yes |
Transfer Time |
0 ns |
Receptacle Detail |
1 x Terminal Block |
Management
Network Management |
SNMP/HTTP Remote Monitoring |
Alarm |
Overload |
UPS Fault |
Over-charge |
Overheat |
Low Battery |
Battery Mode |
Battery Information
Battery Chemistry |
Lead Acid |
Battery Size |
12V |
Battery Capacity |
7000 mAh |
Backup/Run Time (Half Load) |
7.20 Minute |
Backup/Run Time (Full Load) |
17.60 Minute |
Battery Characteristics |
Sealed |
Replaceable Battery |
No |
Typical Battery Recharge Time |
7 Hour |
General Information
Product Type |
Double Conversion Online UPS |
Manufacturer Part Number |
OLS6000ERT6UM |
Manufacturer Website Address |
http://www.cyberpower.com/au |
Manufacturer |
CyberPower Systems, Inc |
Product Model |
OLS6000ERT6UM |
Product Name |
Online S OLS6000ERT6UM 6000VA Tower/Rack Mountable UPS |
Product Line |
Online S |
Brand Name |
CyberPower |
Power Description
Input Voltage |
230 V AC |
Output Voltage |
220 V AC |
240 V AC |
230 V AC |
208 V AC |
Load Capacity |
6 kVA/5.40 kW |
Surge Energy Rating |
445 J |
Waveform Type |
Pure Sine Wave |
Input Voltage Range |
110 V AC – 276 V AC |
